WIWA Spray Equipment    ◇Freeland paint Spray Equipmentt      ◇Inner Pipe Coater
Spray gun        Spray tip

Product Infomation
Model
FLS-K-154
Data
Pressure ratio: 56 : 1  Weight (kgs) :  Size(cm) :
Output (GPM) L/min: 13 (3.43GPM)
  Max Pressure : 5600psi / 380bar
  Air Pressure Range : 40~90psi / 3-6.2bar/0.3~0.62Mpa
  Max Pump Speed (CYCLE/min) : 60
  Stroke(mm) : (CYCLE/min): 60
Applicable paints High viscosity paints
Application Shipbuild, steel structure, construction paint.

Product Infomation
Model
FLS-K-157
Pressure ratio : 68 : 1  Weight (kgs) : 85  Size(cm) : 73x75x127
Output(GPM) L/min : 11 (2 3/4GPM)
  Max Pressure : 6,120psi / 422bar/42.2Mpa
  Air Pressure Range :40~90psi / 3-6.2bar/0.3~0.62Mpa
  Max Pump Speed (CYCLE/min) : 50
  Stroke (mm): 127 (5inch)
Applicable paints High viscosity paints
Application Shipbuild, steel structure, construction paint.

Product Infomation
Model
FLS-K-156
Data
Pressure Ratio : 63 : 1 Weight (kgs): 83  Size(cm): 73x75x125
Output(GPM) L/min : 11 (2 3/4GPM)
  Max Pressure : 5670psi / 390bar/39Mpa
  Air Pressure Range : 40~90psi / 3-6.2bar/0.3~0.62Mpa
  Max Pump Speed (CYCLE/min) : 50
  Stroke (mm) : 120 (4 3/4inch)
Applicable paints High viscosity paints
Application Shipbuild, steel structure, construction paint.

Product Infomation
Model FLS-K-152
Data 4050psi / 280bar/28Mpa
  Air Pressure Range :40~90psi / 3-6.2bar/0.3~0.62Mpa
  Max Pump Speed (CYCLE/min) : 50
  Stroke(mm): 120 (4 3/4inch)
Applicable paints High viscosity paints
Application Shipbuild, steel structure, construction paint.
